Safety and quality are almost the top priority

1) All the designed structure are considered the most serious condition when you facing on the ocean which means our boats are strong and robust .

2) CCS marine aluminum plate and top qualified welder to make the all the welding are good and no cracking when punch on the waves .

3）QC inspection are made for every progress of the manufacture steps to make no mistakes on quality .

4） All the bolts and nuts are 316 stainless to prevent rust .



More funtions and Humanize design are involved in this design .

1) More confortable captain and co captain seat and rear passenger seat for easy on the sea .

2)  A lot of rails on the gunnel and roof and cabin to make sure safety when high speed on the sea .

3) High flotation for the boat to make sure the top standard safety .





7.5m Technical Parameters

Length Beam Depth Thickness(bottom) Thickness(deck)
7.5m 2.45m 1.45m 5mm 4mm
Thickness(transom) Weight(without engine) Recommend Power Max HP Passenger
5mm 1695kg 200hp 300hp 10



6.25m Technical Parameters

Length Beam Depth Thickness(bottom) Thickness(deck)
6.25m 2.5m 1.25m 5mm 4mm
Thickness(transom) Weight(without engine) Recommend Power Speed Passenger
5mm 950kg 200hp 49km/h 6



9.5m Technical Parameters

Length Empty displacement Payload Beam Depth
9.50m 3.5T 1100kg 2.60m 1.41
Cruising ability Material Power Speed Crew
60km Aluminum 150hp*2 30knots 2



5.9m Technical Parameters

Length Average draft Waterline Beam Depth
5.9m 0.35m 5.2m 2.3m 1.25m
Displacement Weight(without engine) Recommend power Speed Passenger
1.1t 600kg 140hp 49km/h 6
